| Part Number | 25339NLD |
|---|
| Manufacturer | Apem Inc. |
|---|
| Description | SWITCH SLIDE SPDT 100MA 30V |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Switches |
|---|
| Series | 25000N |
|---|
| Family | Slide Switches |
|---|
| Standard Package | 100 |
|---|
| Packaging | Bulk |
|---|
| Circuit | SPDT |
|---|
| Contact Timing | Not Specified |
|---|
| Switch Function | On-Off-On |
|---|
| Current Rating | 100mA (DC) |
|---|
| Voltage Rating - AC | - |
|---|
| Voltage Rating - DC | 30V |
|---|
| Actuator Type | Standard |
|---|
| Actuator Length | 2.30mm |
|---|
| Contact Material | Brass |
|---|
| Contact Finish | Gold |
|---|
| Mounting Type | Through Hole, Right Angle |
|---|
| Termination Style | PC Pin |
|---|
| Features | Epoxy Sealed Terminals |
|---|
| Actuator Material | Polyamide (PA), Nylon, Glass Filled |
|---|
| Switch Travel | 4.00mm |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Mechanical Life | 20,000 Cycles |
|---|
| Electrical Life | 10,000 Cycles |
|---|
| Operating Force | - |
|---|
| Online Catalog | 25000N |
|---|
| Other Names | 25339NLD-ND679-1895 |
|---|
