| Part Number | AC1150 |
|---|---|
| Manufacturer | Acme Electric/Amveco/Actown |
| Description | TRANSFORMER CURRENT 150 AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10,000 |
| Datasheet | AC1150 |
| Minimum Order: $100 USD | |
| Request for Quote to us through Email or Phone call on quanitities greater than those displayed or for price adjustment. | |
AC1150
-
- USD 0.00
Product Details
| Part Number | AC1150 |
|---|---|
| Manufacturer | Acme Electric/Amveco/Actown |
| Description | TRANSFORMER CURRENT 150 AMP |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Category | Transformers |
| Series | - |
| Family | Current Sense Transformers |
| Standard Package | 17 |
| Turns Ratio - Primary:Secondary | 1000 : 1 |
| Frequency | 50Hz ~ 60Hz |
| Inductance | - |
| Current Rating | 150A |
| DC Resistance (DCR) | 11 Ohm |
| E.T. | - |
| Mounting Type | Through Hole |
| Size / Dimension | 55.60mm L x 20.60mm W |
| Height - Seated (Max) | 55.60mm |
| Termination Style | PC Pin |
| Other Names | AC-1150TAC-1150TE1150 |
