| Part Number | ALE1D-2M4-10-Z |
|---|
| Manufacturer | Copal Electronics Inc. |
|---|
| Description | SWITCH ROCKER SPDT 50MA 48V |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Switches |
|---|
| Series | ALE |
|---|
| Family | Rocker Switches |
|---|
| 3D Model |
ALE1D-2M4-10-Z
|
|---|
| Standard Package | 50 |
|---|
| Packaging | Bulk |
|---|
| Circuit | SPDT |
|---|
| Switch Function | On-On |
|---|
| Current Rating | 50mA (AC/DC) |
|---|
| Voltage Rating - AC | 48V |
|---|
| Voltage Rating - DC | 48V |
|---|
| Actuator Type | Actuator Arm, Cap Required |
|---|
| Color - Actuator/Cap | - |
|---|
| Actuator Marking | Varies by Cap |
|---|
| Illumination Type, Color | - |
|---|
| Illumination Voltage (Nominal) | - |
|---|
| Mounting Type | Through Hole |
|---|
| Termination Style | PC Pin |
|---|
| Ingress Protection | - |
|---|
| Features | Sealed - Fully |
|---|
| Panel Cutout Dimensions | - |
|---|
| Operating Temperature | -20°C ~ 85°C |
|---|
| Mechanical Life | - |
|---|
| Electrical Life | 10,000 Cycles |
|---|
| Online Catalog | ALE Series |
|---|
| Associated Product | 563-1205-ND - CAP ROCKER RECTANGULAR BLACK563-1203-ND - CAP ROCKER PADDLE BLACK563-1204-ND - CAP ROCKER PADDLE WHITE563-1206-ND - CAP ROCKER RECTANGULAR WHITE |
|---|
| Other Names | 563-1201ALE1D-2M4-10-Z-NDALE1D2M410Z |
|---|
