| Part Number | 7914J-1-000 |
|---|---|
| Manufacturer | Bourns Inc. |
| Description | SWITCH TACTILE SPST-NO 0.1A 16V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 1,485 |
| Datasheet | 7914J-1-000 |
| Minimum Order: $100 USD | |
| Request for Quote to us through Email or Phone call on quanitities greater than those displayed or for price adjustment. | |
7914J-1-000
-
- USD 0.96
Product Details
| Part Number | 7914J-1-000 |
|---|---|
| Manufacturer | Bourns Inc. |
| Description | SWITCH TACTILE SPST-NO 0.1A 16V |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Category | Switches |
| Series | 7914 |
| Family | Tactile Switches |
| Standard Package | 50 |
| Packaging | Tube |
| Circuit | SPST-NO |
| Switch Function | Off-Mom |
| Contact Rating @ Voltage | 0.1A @ 16VAC/DC |
| Actuator Type | Standard |
| Mounting Type | Surface Mount |
| Actuator Height off PCB, from Pins | 4.19mm |
| Actuator Orientation | Top Actuated |
| Termination Style | J Lead |
| Outline | 5.00mm x 5.00mm |
| Illumination | Non-Illuminated |
| Illumination Voltage (Nominal) | - |
| Illumination Type, Color | - |
| Operating Force | 300gf |
| Ingress Protection | - |
| Features | - |
| Actuator Material | Silicon Rubber |
| Switch Travel | - |
| Mechanical Life | 100,000 Cycles |
| Operating Temperature | -55°C ~ 125°C |
| Online Catalog | 7914 Series |
| Other Names | 7914J1000 |
