| Part Number | CAS-220TA |
|---|
| Manufacturer | Copal Electronics Inc. |
|---|
| Description | SLIDE SWITCH DPDT J HOOK 6V |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Switches |
|---|
| Series | CAS |
|---|
| Family | DIP Switches |
|---|
| Product Training Modules |
CJS & CAS Slide Switches
|
|---|
| Featured Product |
CJS and CAS Series Surface-Mount Slide Switches
|
|---|
| 3D Model |
CAS-220TA
|
|---|
| Standard Package | 1 |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Circuit | DPDT |
|---|
| Number of Positions | 2 |
|---|
| Current Rating | 100mA |
|---|
| Voltage Rating | 6VDC |
|---|
| Actuator Type | Slide (Standard) |
|---|
| Actuator Level | Flush, Recessed |
|---|
| Contact Material | Copper Alloy |
|---|
| Contact Finish | Gold |
|---|
| Height Above Board | 0.098" (2.50mm) |
|---|
| Mounting Type | Surface Mount |
|---|
| Termination Style | J Lead |
|---|
| Pitch | 0.068" (1.75mm) |
|---|
| Washable | Yes |
|---|
| Features | Tape Seal |
|---|
| Body Material | Polyphenylene Sulfide (PPS) |
|---|
| Length | 0.212" (5.40mm) |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Mechanical Life | - |
|---|
| Electrical Life | 2,000 Cycles |
|---|
| Online Catalog | CAS Series |
|---|
| Other Names | CAS220JCT |
|---|
