| Part Number | MICRF112YMM |
|---|
| Manufacturer | Microchip Technology |
|---|
| Description | IC XMITTER UHF ASK/FSK 10-MSOP |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | RF/IF and RFID |
|---|
| Series | QwikRadio? |
|---|
| Family | RF Transmitters |
|---|
| Mfg Application Notes |
How to go Through FCC Compliance Testing Using the MICRF112
|
|---|
| Design Resources |
Development Tool Selector
|
|---|
| PCN Design/Specification |
Silver Bonding Wire 22/Jul/2015
|
|---|
| PCN Assembly/Origin |
Qualification Assembly Site 03/Mar/2014
Multiple Devices Datasheet Update 15/Aug/2014
|
|---|
| Standard Package | 100 |
|---|
| Packaging | Tube |
|---|
| Frequency | 300MHz ~ 450MHz |
|---|
| Applications | RKE, TPM |
|---|
| Modulation or Protocol | ASK, FSK |
|---|
| Data Rate (Max) | 50 kbps |
|---|
| Power - Output | 10dBm |
|---|
| Current - Transmitting | 11mA |
|---|
| Data Interface | PCB, Surface Mount |
|---|
| Antenna Connector | PCB, Surface Mount |
|---|
| Memory Size | - |
|---|
| Features | - |
|---|
| Voltage - Supply | 1.8 V ~ 3.6 V |
|---|
| Operating Temperature | -40°C ~ 125°C |
|---|
| Package / Case | 10-TFSOP, 10-MSOP (0.118", 3.00mm Width) |
|---|
| Online Catalog | MICRF112 |
|---|
| For Use With | 576-4909-ND - EVAL BOARD FOR MICRF112 315MHZ576-3603-ND - EVAL BOARD UHF ASK/FSK TRANSMIT535-10149-2-ND - CRYSTAL 13.0625MHZ 10PF SMD535-10149-1-ND - CRYSTAL 13.0625MHZ 10PF SMD535-10149-6-ND - CRYSTAL 13.0625MHZ 10PF SMD535-10151-2-ND - CRYSTAL 13.5600MHZ 10PF SMD535-10151-1-ND - CRYSTAL 13.5600MHZ 10PF SMD535-10151-6-ND - CRYSTAL 13.5600MHZ 10PF SMD535-10152-2-ND - CRYSTAL 9.84375MHZ 10PF SMD535-10152-1-ND - CRYSTAL 9.84375MHZ 10PF SMD535-10152-6-ND - CRYSTAL 9.84375MHZ 10PF SMD |
|---|
| Other Names | 576-1963-5MICRF112YMM-ND |
|---|
