| Part Number | 2450AD46A5400E |
|---|---|
| Manufacturer | Johanson Technology Inc. |
| Description | DUALBAND ANT 2.4/5.5GHZ WIFI |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10,000 |
| Datasheet | 2450AD46A5400E |
| Minimum Order: $100 USD | |
| Request for Quote to us through Email or Phone call on quanitities greater than those displayed or for price adjustment. | |
2450AD46A5400E
-
- USD 0.00
Product Details
| Part Number | 2450AD46A5400E |
|---|---|
| Manufacturer | Johanson Technology Inc. |
| Description | DUALBAND ANT 2.4/5.5GHZ WIFI |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Category | RF/IF and RFID |
| Series | - |
| Family | RF Antennas |
| Product Training Modules | RF Ceramic Chip Antennas |
| Standard Package | 1 |
| Packaging | * |
| Frequency Group | UHF (2 GHz ~ 3 GHz), SHF (f > 4 GHz) |
| Frequency (Center/Band) | 2.4GHz, 5.4GHz |
| Frequency Range | 2.4GHz ~ 2.5GHz, 4.9GHz ~ 5.9GHz |
| Antenna Type | Chip |
| Number of Bands | 2 |
| VSWR | - |
| Return Loss | -8.5dB |
| Gain | 1dBi, -1.5dBi |
| Power - Max | 3W |
| Features | - |
| Termination | Solder |
| Ingress Protection | - |
| Mounting Type | Surface Mount |
| Height (Max) | 0.047" (1.20mm) |
| Applications | - |
| Other Names | 712-1000-1 |
