| Part Number | G5SB-14 DC5 |
|---|
| Manufacturer | Omron Electronics Inc-EMC Div |
|---|
| Description | RELAY GENERAL PURPOSE SPDT 5A 5V |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Relays |
|---|
| Series | G5SB |
|---|
| Family | Power Relays, Over 2 Amps |
|---|
| Other Related Documents |
How to Read Date Codes
|
|---|
| Product Training Modules |
Medical Solutions
|
|---|
| Featured Product |
DC Power Relays G9EA/G9EB/G9EC Series
|
|---|
| Standard Package | 100 |
|---|
| Packaging | Bulk |
|---|
| Relay Type | General Purpose |
|---|
| Coil Type | Non Latching |
|---|
| Coil Current | 80mA |
|---|
| Coil Voltage | 5VDC |
|---|
| Contact Form | SPDT (1 Form C) |
|---|
| Contact Rating (Current) | 5A |
|---|
| Switching Voltage | 250VAC, 30VDC - Max |
|---|
| Turn On Voltage (Max) | 3.75 VDC |
|---|
| Turn Off Voltage (Min) | 0.25 VDC |
|---|
| Operate Time | 10ms |
|---|
| Release Time | 5ms |
|---|
| Features | Sealed - Fully |
|---|
| Mounting Type | Through Hole |
|---|
| Termination Style | PC Pin |
|---|
| Contact Material | Silver Alloy |
|---|
| Coil Power | 400 mW |
|---|
| Coil Resistance | 63 Ohms |
|---|
| Operating Temperature | -40°C ~ 70°C |
|---|
| Online Catalog | G5SB Series |
|---|
| Other Names | G5SB-14 5DCNG5SB-14-5DCNG5SB-14-DC5G5SB145DCG5SB145DCNG5SB14DC5G9EC1101GZ1640 |
|---|
