| Part Number | DCR012405P |
|---|
| Manufacturer | Texas Instruments |
|---|
| Description | IC REG ISOLATED 5V 0.2A 10DIP |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Power Supplies - Board Mount |
|---|
| Series | DCR01 |
|---|
| Family | DC DC Converters |
|---|
| Manufacturer Product Page |
DCR012405P Specifications
|
|---|
| Standard Package | 20 |
|---|
| Packaging | Tube |
|---|
| Type | Isolated Module |
|---|
| Number of Outputs | 1 |
|---|
| Voltage - Input (Min) | 21.6V |
|---|
| Voltage - Input (Max) | 26.4V |
|---|
| Voltage - Output 1 | 5V |
|---|
| Voltage - Output 2 | - |
|---|
| Voltage - Output 3 | - |
|---|
| Current - Output (Max) | 200mA |
|---|
| Power (Watts) - Manufacture Series | 1W |
|---|
| Voltage - Isolation | 1kV (1000V) |
|---|
| Applications | ITE (Commercial) |
|---|
| Features | Remote On/Off, OTP, SCP |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | 18-DIP Module (10 Leads) |
|---|
| Size / Dimension | 0.90" L x 0.28" W x 0.21" H (22.9mm x 7.1mm x 5.3mm) |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Efficiency | - |
|---|
| Power (Watts) - Max | 1W |
|---|
| Online Catalog | DCR01 Series |
|---|
| Other Names | 296-9456-5 |
|---|
