| Part Number | ATA010A0X3-SRZ |
|---|
| Manufacturer | GE Critical Power |
|---|
| Description | CONVER DC/DC 0.75 5.5V @ 10A SMD |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Power Supplies - Board Mount |
|---|
| Series | Austin Lynx? II |
|---|
| Family | DC DC Converters |
|---|
| Product Training Modules |
End-to-End Power Solutions for the Building, Box and Board
|
|---|
| Manufacturer Product Page |
Power Module Wizard™
|
|---|
| Standard Package | 1 |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Type | Non-Isolated PoL Module |
|---|
| Number of Outputs | 1 |
|---|
| Voltage - Input (Min) | 8.3V |
|---|
| Voltage - Input (Max) | 14V |
|---|
| Voltage - Output 1 | 0.8 ~ 5.5 V |
|---|
| Voltage - Output 2 | - |
|---|
| Voltage - Output 3 | - |
|---|
| Current - Output (Max) | 10A |
|---|
| Power (Watts) - Manufacture Series | 55W |
|---|
| Voltage - Isolation | - |
|---|
| Applications | ITE (Commercial) |
|---|
| Features | With Remote On/Off |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 7-SMD Module |
|---|
| Size / Dimension | 1.30" L x 0.53" W x 0.33" H (33.0mm x 13.5mm x 8.3mm) |
|---|
| Operating Temperature | -40°C ~ 85°C |
|---|
| Efficiency | 93% |
|---|
| Power (Watts) - Max | 55W |
|---|
| Online Catalog | Austin Lynx? II Series |
|---|
| Other Names | 555-1077-1 |
|---|
