| Part Number | VO3120-X007T |
|---|
| Manufacturer | Vishay Semiconductor Opto Division |
|---|
| Description | OPTOISO 5.3KV GATE DRIVER 8SMD |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Isolators |
|---|
| Series | - |
|---|
| Family | Isolators - Gate Drivers |
|---|
| Product Training Modules |
Opto IGBT / MOSFET Driver
|
|---|
| Featured Product |
Optically Isolated IGBT/MOSFET Driver
|
|---|
| EDA / CAD Models |
Download from Accelerated Designs |
|---|
| Standard Package | 1 |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Technology | Optical Coupling |
|---|
| Number of Channels | 1 |
|---|
| Voltage - Isolation | 5300Vrms |
|---|
| Common Mode Transient Immunity (Min) | 25kV/μs |
|---|
| Propagation Delay tpLH / tpHL (Max) | 400ns, 400ns |
|---|
| Pulse Width Distortion (Max) | 200ns |
|---|
| Rise / Fall Time (Typ) | 100ns, 100ns |
|---|
| Current - Output High, Low | 2.5A, 2.5A |
|---|
| Current - Peak Output | 2.5A |
|---|
| Voltage - Forward (Vf) (Typ) | 1.6V (Max) |
|---|
| Current - DC Forward (If) (Max) | 25mA |
|---|
| Voltage - Supply | 15 V ~ 32 V |
|---|
| Operating Temperature | -40°C ~ 110°C |
|---|
| Mounting Type | Surface Mount |
|---|
| Package / Case | 8-SMD (300 mil) |
|---|
| Supplier Device Package | 8-SMD |
|---|
| Approvals | cUR, UR |
|---|
| Online Catalog | Gate Drivers |
|---|
| Other Names | 751-1475-1 |
|---|
