| Part Number | MOC3023X |
|---|
| Manufacturer | Isocom Components 2004 LTD |
|---|
| Description | OPTOISOLATOR 5.3KV TRIAC 6DIP |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Isolators |
|---|
| Series | - |
|---|
| Family | Optoisolators - Triac, SCR Output |
|---|
| Standard Package | 1,040 |
|---|
| Packaging | Tube |
|---|
| Output Type | Triac |
|---|
| Zero Crossing Circuit | No |
|---|
| Number of Channels | 1 |
|---|
| Voltage - Isolation | 5300Vrms |
|---|
| Voltage - Off State | 400V |
|---|
| Static dV/dt (Min) | 10V/μs (Typ) |
|---|
| Current - LED Trigger (Ift) (Max) | 5mA |
|---|
| Current - On State (It (RMS)) (Max) | - |
|---|
| Current - Hold (Ih) | 100μA |
|---|
| Turn On Time | - |
|---|
| Voltage - Forward (Vf) (Typ) | 1.2V |
|---|
| Current - DC Forward (If) (Max) | 50mA |
|---|
| Operating Temperature | -40°C ~ 100°C |
|---|
| Mounting Type | Through Hole |
|---|
| Package / Case | 6-DIP (0.300", 7.62mm) |
|---|
| Supplier Device Package | - |
|---|
| Approvals | UR, VDE |
|---|
| Online Catalog | MOC3020(X), MOC3021(X), MOC3022(X), MOC3023(X) Series |
|---|
