| Part Number | MPC8347VVAJFB |
|---|
| Manufacturer | Freescale Semiconductor |
|---|
| Description | IC MPU MPC83XX 533MHZ 672TBGA |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Integrated Circuits (ICs) |
|---|
| Series | MPC83xx |
|---|
| Family | Embedded - Microprocessors |
|---|
| PCN Design/Specification |
Copper Bond Wire Qualification 07/Sep/2014
|
|---|
| Standard Package | 48 |
|---|
| Packaging | Tray |
|---|
| Core Processor | PowerPC e300 |
|---|
| Number of Cores/Bus Width | 1 Core, 32-Bit |
|---|
| Speed | 533MHz |
|---|
| Co-Processors/DSP | - |
|---|
| RAM Controllers | DDR |
|---|
| Graphics Acceleration | No |
|---|
| Display & Interface Controllers | - |
|---|
| Ethernet | 10/100/1000 Mbps (2) |
|---|
| SATA | - |
|---|
| USB | USB 2.0 + PHY (2) |
|---|
| Voltage - I/O | 2.5V, 3.3V |
|---|
| Operating Temperature | 0°C ~ 105°C |
|---|
| Security Features | - |
|---|
| Package / Case | 672-LBGA |
|---|
| Supplier Device Package | 672-TBGA (35x35) |
|---|
| Additional Interfaces | DUART, I2C, PCI, SPI |
|---|
| Online Catalog | MPC83xx |
|---|
| For Use With | CWH-CTP-BASE-HE-ND - CW USB ETH TAP BASE UNIT |
|---|
