| Part Number | BD680 |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | TRANS PNP DARL 80V 4A TO225 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Quantity Available | 10,000 |
| Datasheet | BD680 |
| Minimum Order: $100 USD | |
| Request for Quote to us through Email or Phone call on quanitities greater than those displayed or for price adjustment. | |
BD680
-
- USD 0.00
Product Details
| Part Number | BD680 |
|---|---|
| Manufacturer | ON Semiconductor |
| Description | TRANS PNP DARL 80V 4A TO225 |
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
| Category | Discrete Semiconductor Products |
| Series | - |
| Family | Transistors (BJT) - Single |
| EDA / CAD Models | Download from Accelerated Designs |
| Standard Package | 500 |
| Packaging | Bulk |
| Transistor Type | PNP - Darlington |
| Current - Collector (Ic) (Max) | 4A |
| Voltage - Collector Emitter Breakdown (Max) | 80V |
| Vce Saturation (Max) @ Ib, Ic | 2.5V @ 30mA, 1.5A |
| Current - Collector Cutoff (Max) | 500μA |
| DC Current Gain (hFE) (Min) @ Ic, Vce | 750 @ 1.5A, 3V |
| Power - Max | 40W |
| Frequency - Transition | - |
| Mounting Type | Through Hole |
| Package / Case | TO-225AA, TO-126-3 |
| Supplier Device Package | TO-225AA |
| Other Names | BD680OS |
