| Part Number | 5-916783-2 |
|---|
| Manufacturer | TE Connectivity AMP Connectors |
|---|
| Description | CONN SOCKET PGA ZIF 370POS GOLD |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Connectors, Interconnects |
|---|
| Series | - |
|---|
| Family | Sockets for ICs, Transistors |
|---|
| 3D Model |
5-916783-2.pdf
|
|---|
| Standard Package | 1,120 |
|---|
| Packaging | Tray |
|---|
| Type | PGA, ZIF (ZIP) |
|---|
| Number of Positions or Pins (Grid) | 370 (19 x 19) |
|---|
| Pitch - Mating | 0.100" (2.54mm) |
|---|
| Contact Finish - Mating | Gold |
|---|
| Contact Finish Thickness - Mating | 30μin (0.76μm) |
|---|
| Contact Material - Mating | Phosphor Bronze |
|---|
| Mounting Type | Through Hole |
|---|
| Features | Open Frame |
|---|
| Termination | Solder |
|---|
| Pitch - Post | 0.100" (2.54mm) |
|---|
| Contact Finish - Post | Gold |
|---|
| Contact Finish Thickness - Post | 30μin (0.76μm) |
|---|
| Contact Material - Post | Phosphor Bronze |
|---|
| Housing Material | Liquid Crystal Polymer (LCP) |
|---|
| Operating Temperature | - |
|---|
| Termination Post Length | 0.110" (2.78mm) |
|---|
| Material Flammability Rating | UL94 V-0 |
|---|
| Current Rating | - |
|---|
| Contact Resistance | - |
|---|
