| Part Number | 103958-9 |
|---|
| Manufacturer | TE Connectivity AMP Connectors |
|---|
| Description | CONN RECPT 10POS .100 POLAR 30AU |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Connectors, Interconnects |
|---|
| Series | AMPMODU MTE |
|---|
| Family | Rectangular Connectors - Free Hanging, Panel Mount |
|---|
| Product Training Modules |
AMPMODU MTE Interconnect
|
|---|
| Featured Product |
AMPMODU Connectors
|
|---|
| 3D Model |
103958-9.pdf
|
|---|
| Standard Package | 22 |
|---|
| Packaging | Tube |
|---|
| Connector Type | Receptacle |
|---|
| Contact Type | Female Socket |
|---|
| Number of Positions | 10 |
|---|
| Pitch | 0.100" (2.54mm) |
|---|
| Number of Rows | 1 |
|---|
| Row Spacing | - |
|---|
| Mounting Type | Free Hanging (In-Line) |
|---|
| Fastening Type | Latch Lock |
|---|
| Cable Termination | IDC |
|---|
| Wire Type | Discrete or Ribbon Cable |
|---|
| Wire Gauge | 22-26 AWG |
|---|
| Features | Closed End |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Color | Black |
|---|
| Online Catalog | AMPMODU MTE Series |
|---|
| Mating Products | A34234-ND - CONN PLUG 10POS .100 POLAR 15AUA33945-ND - CONN HEADER VERT 10POS PCB TINA33854-ND - CONN HEADER RT/A .100 10POS 15AUA33878-ND - CONN HEADER RT/A .100 10POS 15AUA34233-ND - CONN PLUG 10POS .100 POLAR 30AUA34349-ND - CONN HEADER RTANG 10POS PCB TINA33908-ND - CONN HEADER VERT 10POS PCB TI |
|---|
| Tooling | A28718-ND - HEAD (IDC) MODU MTE W/O TL |
|---|
| Other Names | 103958-9-ND1039589A28422 |
|---|
