| Part Number | 3503 |
|---|
| Manufacturer | Keystone Electronics |
|---|
| Description | JACK .015-.025".203"L PRESS FIT |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Connectors, Interconnects |
|---|
| Series | - |
|---|
| Family | Terminals - PC Pin Receptacles, Socket Connectors |
|---|
| Standard Package | 100 |
|---|
| Packaging | Bulk |
|---|
| Tail Type | No Tail |
|---|
| Termination | Press-Fit |
|---|
| Length - Overall | 0.203" (5.16mm) |
|---|
| Accepts Pin Diameter | 0.015" ~ 0.025" (0.38mm ~ 0.64mm) |
|---|
| Mounting Hole Diameter | 0.057" (1.45mm) |
|---|
| Pin Hole Diameter | - |
|---|
| Flange Diameter | 0.072" (1.83mm) |
|---|
| Tail Diameter | - |
|---|
| Socket Depth | 0.160" (4.06mm) |
|---|
| Contact Material | Beryllium Copper |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 10μin (0.25μm) |
|---|
| Features | - |
|---|
| Operating Temperature | - |
|---|
| Board Thickness | - |
|---|
| Insertion Force | - |
|---|
| Other Names | 3503K3503K-ND36-3503 |
|---|
