| Part Number | HR10-10R-12SA(73) |
|---|
| Manufacturer | Hirose Electric Co Ltd |
|---|
| Description | CONN RECEPT 12POS FEMALE DIP PCB |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Connectors, Interconnects |
|---|
| Series | HR10 |
|---|
| Family | Circular Connectors |
|---|
| Standard Package | 50 |
|---|
| Packaging | Tray |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 12 |
|---|
| Shell Size - Insert | 10 |
|---|
| Shell Size, MIL | - |
|---|
| Mounting Type | Panel Mount, Bulkhead; Through Hole |
|---|
| Termination | Solder |
|---|
| Fastening Type | Push-Pull |
|---|
| Orientation | Keyed |
|---|
| Ingress Protection | - |
|---|
| Shell Material, Finish | Brass and Zinc, Nickel Plated |
|---|
| Contact Finish | Gold |
|---|
| Features | - |
|---|
| Contact Finish Thickness | - |
|---|
| Current Rating | 2A |
|---|
| Voltage - Rated | 100VAC |
|---|
| Operating Temperature | -25°C ~ 85°C |
|---|
| Online Catalog | HR10 Series |
|---|
| Mating Products | HR1562-ND - PLUG W/PIN INSERT (12 CONTACT) |
|---|
| Associated Product | HR349-ND - CONN DUST CAP FOR 10-12POS RECPTHR10A-10R-W-ND - CONN LOCKWASHER SZ 10HR10A-10R-N-ND - CONN HEX NUT SZ 10 |
|---|
| Other Names | *HR10-10R-12SA(73)HR10-10R-12SA(73)-NDHR1010R12SA73HR1576Q2681077 |
|---|
