| Part Number | 557984-1 |
|---|
| Manufacturer | TE Connectivity AMP Connectors |
|---|
| Description | RCPT ASSY,50PO,SHLD,A/PIN,CHAM |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Connectors, Interconnects |
|---|
| Series | CHAMP .085 |
|---|
| Family | D-Shaped Connectors - Centronics |
|---|
| 3D Model |
557984-1.pdf
|
|---|
| Standard Package | 20 |
|---|
| Connector Style | Outer Shroud Contacts |
|---|
| Connector Type | Receptacle |
|---|
| Number of Positions | 50 |
|---|
| Number of Rows | 2 |
|---|
| Mounting Type | Through Hole |
|---|
| Termination | Press-Fit |
|---|
| Flange Feature | Insert, Threaded (4-40) |
|---|
| Type | - |
|---|
| Features | Shielded |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Online Catalog | CHAMP .085 Series |
|---|
| Mating Products | 1116719-1-ND - CONN CHAMP PLUG 50POS .085 SHLD1116719-3-ND - CONN CHAMP PLUG 50POS .085 SHLD |
|---|
| Other Names | 557984-1-ND5579841A24395 |
|---|
