| Part Number | 1-747301-6 |
|---|
| Manufacturer | TE Connectivity AMP Connectors |
|---|
| Description | CONN D-SUB RCPT 37POS VERT SLDR |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Connectors, Interconnects |
|---|
| Series | AMPLIMITE HD-20 |
|---|
| Family | D-Sub Connectors |
|---|
| 3D Model |
1-747301-6.pdf
|
|---|
| Standard Package | 441 |
|---|
| Packaging | Bulk |
|---|
| Connector Style | D-Sub |
|---|
| Connector Type | Receptacle, Female Sockets |
|---|
| Number of Positions | 37 |
|---|
| Number of Rows | 2 |
|---|
| Shell Size, Connector Layout | 4 (DC, C) |
|---|
| Contact Type | Signal |
|---|
| Mounting Type | Through Hole |
|---|
| Flange Feature | Mating Side; Female Screwlock (4-40) |
|---|
| Termination | Solder |
|---|
| Features | - |
|---|
| Shell Material, Finish | Steel, Tin Plated |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | 30μin (0.76μm) |
|---|
| Ingress Protection | - |
|---|
| Operating Temperature | -55°C ~ 105°C |
|---|
| Voltage Rating | 125V |
|---|
| Current Rating | 6A |
|---|
| Housing Material | Polyester |
|---|
| Color | Black |
|---|
| Mating Products | AML37B-ND - CONN DSUB PLUG 37POS STR IDC |
|---|
| Other Names | A23198 |
|---|
