| Part Number | AXK6F80347YG |
|---|
| Manufacturer | Panasonic Electric Works |
|---|
| Description | CONN HEADER BRD/BRD .5MM 80POS |
|---|
| Lead Free Status / RoHS Status | Lead free / RoHS Compliant |
|---|
| Category | Connectors, Interconnects |
|---|
| Series | P5KF |
|---|
| Family | Rectangular - Board to Board Connectors - Arrays, Edge Type, Mezzanine |
|---|
| Other Related Documents |
How to Read Date Codes
|
|---|
| Featured Product |
Hot New Technologies
|
|---|
| Standard Package | 1 |
|---|
| Packaging | Cut Tape (CT) |
|---|
| Connector Type | Header, Center Strip Contacts |
|---|
| Number of Positions | 80 |
|---|
| Pitch | 0.020" (0.50mm) |
|---|
| Number of Rows | 2 |
|---|
| Mounting Type | Surface Mount |
|---|
| Features | - |
|---|
| Contact Finish | Gold |
|---|
| Contact Finish Thickness | - |
|---|
| Mated Stacking Heights | 1.5mm, 2mm |
|---|
| Height Above Board | 0.049" (1.25mm) |
|---|
| Online Catalog | P5KF Series |
|---|
| Mating Products | 255-3228-2-ND - CONN SOCKET BRD/BRD .5MM 80POS255-3228-1-ND - CONN SOCKET BRD/BRD .5MM 80POS255-3126-2-ND - CONN SOCKET BRD/BRD .5MM 80POS255-3126-1-ND - CONN SOCKET BRD/BRD .5MM 80POS255-3126-6-ND - CONN SOCKET BRD/BRD .5MM 80POSAXK5F80337YG-ND - CONN SOCKET BRD/BRD .5MM 80POSAXK5F80537YG-ND - CONN |
|---|
| Other Names | 255-3257-1 |
|---|
